Ավտոմատ փոխանցման յուղ ժամանակակից 8-աստիճան AISIN փոխանցման տուփերի համար, որոնք տեղադրված են BMW, Peugeot, Citroen, Volvo, Opel, Volkswagen, DS մեքենաներում: Բնօրինակ հեղուկների անալոգն է VW G053001A2, VOLVO 31492172 / 31492173, PSA 1635056080, BMW 83222413477, BMW ATF 7, ATF AW-2
RAVENOL ATF T-ULV Fluid is a full synthetic ATF (Automatic Transmission Fluid), designed on the basis of high quality polyalphaolefin (PAO) and Esters with a special additive and inhibition, which ensure a perfect function of the automatic transmission.
RAVENOL ATF T-ULV Fluid is an ATF for the latest generation of Aisin Warner automatic transmissions. It guarantees a high wear protection in all operating conditions. RAVENOL ATF T-ULV Fluid has a red colour.
Reducing loss torque in automatic transmissions (ATFs) is a key factor in improving fuel economy. A promising approach is to reduce the viscosity of the Automatic Transmission Fluid (ATF) to minimize churning loss. RAVENOL has developed an ultra-low viscosity ATF, called “T-ULV”, which has approximately 50% lower kinematic viscosity at 40 °C compared to the conventional low viscosity ATFs. It is generally understood that if the viscosity of an ATF is too low, it can have a negative impact on the fatigue life of components such as gears and bearings, and possibly lead to increased wear or seizure.
RAVENOL ATF T-ULV Fluid was designed to solve these problems via the application of two key technologies. The first is a high performance PAO (Polyalphaolefin) with a low traction coefficient, which translates to low viscosity under high pressure conditions. This decreases the shear resistance between sliding surfaces under elasto-hydrodynamic lubrication (EHL) conditions, which contributes to improving the fatigue life of bearings and other components. The second is an ester type base oil with high polarity. It was found that the amount of ester base oil used has a major influence on fatigue life. The adsorption of esters onto metal surfaces is thought to improve lubricity in severe lubrication conditions. Durability tests were performed in a wide range of conditions, using gear and bearing components and actual transmission units, and it was confirmed that RAVENOL ATF T-ULV Fluid outperforms low viscosity ATFs, despite its ultra-low viscosity.
Furthermore, RAVENOL ATF T-ULV Fluid reduces loss torque in the transmission by approximately 12% compared to other low viscosity ATFs.
Application Note
RAVENOL ATF T-ULV Fluid is an Ultra Low Viscosity ATF for modern 8-Speed automatic transmissions of Aisin Warner: Aisin AWF8G30, AWF8G35, AWF8G45, AWF8G55, BMW GA8F22AW, Citroën EAT8, Mini GA8F22AW, Peugeot ATN8, Toyota Direct Shift-8AT, Volvo AWF8G45, VW 09S (AQ300-8F).
RAVENOL ATF T-ULV Fluid is suitable for use in automatic transmissions of BMW, Peugeot/Citroen, VW, Volvo. Note the original part number of manufacturer!
Characteristics
- Very good lubricity also at low temperatures in winter
- High, stable viscosity index
- Very good oxidation stability
- Excellent wear, corrosion and foaming protection
- Excellent friction constant
- High thermal and oxidative stability
- Excellent cooling capacity
RAVENOL special transmission fluids are special developments for special gears and cannot be selected on the basis of technical parameters (viscosity, etc.). Therefore the decision was made not to give technical data. Please note: RAVENOL special transmission fluid is exclusively to apply under the original number, as indicated in the product information. If you are unsure about the right transmission fluid, ask your workshop or dealership for advice on the transmission type and OEM original number or ask our experts, making sure to state the VIN code (vehicle identification number) of your vehicle. Misapplication of RAVENOL special transmission fluid can lead to malfunction of the transmission shifting problems, increased fuel consumption, unwanted slip behavior, etc. and cause the failure of the transmission. Ravensberger Schmierstoffvertrieb GmbH is not liable for transmission failures in case of wrong selection of RAVENOL special transmission fluid.
Բնութագրերը
Կարգավորում | Արժեք | Աուդիտ |
---|---|---|
Լայնությունը, mm | 580 | |
Երկարություն, mm | 580 | |
Բարձրություն, mm | 885 | |
Brand | RAVENOL | |
Համապատասխանում է | BMW 8-Speed AT BMW GA8G45AW, BMW/Mini GA8F22AW, Citroën EAT8, PSA 16 350 560 80, Volvo 8-Speed AT AWF8G45, Volvo 8-Speed AT AWF8G55, VW 8-Speed AT VW 09S (AQ300-8F) | |
Համապատասխանում է ապրանքներին | BMW 83222413477, Volvo 31492172, Volvo 31492173, VW G 053 001 | |
Հատուկ հզորություն 20°C-ի դեպքում | 819,3 | EN ISO 12185 |
Գույն | Red | տեսողական |
Մածուցիկություն 100 °C-ում, mm²/s | 3.3 | DIN 51562-1 |
Մածուցիկություն 40 °C-ում, mm²/s | 12 | DIN 51562-1 |
Մածուցիկության ինդեքս VI | 151 | DIN ISO 2909 |
Բրուկֆիլդի մածուցիկություն -40°C-ում, mPa*s | 1090 | ASTM D2983 |
Բրուքֆիլդի տեսականություն -50°C-ի դեպքում, մՊա*վրկ | 5800 | ASTM D2983 |
Բրուքֆիլդի տեսականություն -55°C-ի դեպքում, մՊա*վրկ | 7000 | ASTM D2983 |
Բյուրեղացման ջերմաստիճան, °C | -78 | DIN ISO 3016 |
Կառուցման ջերմաստիճան, °C | 164 | DIN EN ISO 2592 |
Չորս գնդիկի քսման մեքենայի փորձարկում (մաշվածություն), mm | 0.6 | DIN 51350-3 |
Փրփուրի առաջացում I՝ 24°C-ում, ml/ml | 10/0 | ASTM D892 |
Փրփուրի առաջացում II՝ 93.5°C-ում, ml/ml | 0/0 | ASTM D892 |
Փրփուրի առաջացում III՝ 24°C-ից մինչև 93.5°C, ml/ml | 10/0 | ASTM D892 |
Փրփրունակություն (Seq. I, II, III) | - | DIN EN 60243-1 (20°C) |
Պղնձյա շերտի փորձարկում 150°C-ում | 1a | ASTM D130 |
Քաշը, kg | 188.805 |
BMW | 83222413477 |
Ford | 196124 |
Jaguar | J9C20481 |
Jaguar | J9C20482 |
Jaguar | J9C20483 |
Land Rover | LR132270 |
Land Rover | LR132272 |
Land Rover | LR132275 |
Peugeot | 1635050280 |
Peugeot | 1635056080 |
Toyota | SU001A7773 |
Volkswagen Group | G053001 |
Volkswagen Group | G053001A2 |
Volkswagen Group | G060540A2 |
Volvo | 31492172 |
Volvo | 31492173 |
Volvo | 31492174 |
Volvo | 32324299 |
