Սինթետիկ հեղուկ ուլտրա-ցածր մածուցիկությամբ (ULV) ավտոմատ փոխանցման տուփերի համար ՝ պոլիալֆաոլեֆինի, էսթերների և բարձրորակ հիդրոկրեկինգային յուղերի հիման վրա ՝ հատուկ հավելանյութերով և արգելակիչներով, որոնք ապահովում են ավտոմատ փոխանցման տուփի անթերի աշխատանքը:
RAVENOL ATF ULV D-M is a Ultra Low Viscosity (ULV) Automatic Transmission Fluid (ATF), designed on the basis of PAO (Polyalphaolefin), Ester and highquality hydrocrack oils with a special additive and inhibition, which ensure a perfect function of the automatic transmission.
RAVENOL ATF ULV D-M is an ATF (Automatic Transmission Fluid) developed for the latest 6, 8 and 10 speed automatic transmissions from Ford and GM.
RAVENOL ATF ULV D-M guarantees maximum wear protection in all operating conditions and offers reduced fuel consumption.
Application Note
RAVENOL ATF ULV D-M was developed for use in 6, 8 and 10 speed automatic transmissions, especially from Ford and GM.
RAVENOL ATF ULV D-M is particularly suitable when the Ford WSS-M2C949-A specification is required.
It is recommended to flush with RAVENOL ATF ULV D-M before filling with RAVENOL ATF ULV D-M.
RAVENOL ATF ULV D-M is particularly suitable for
Ford 6-speed transmissions 6F15
Ford 8-speed automatic transmissions 8F24, 8F35, 8F40, 8F57
Ford 10-speed 10R60, 10R80-MHT, 10R80, 10R140
GM 10-speed 10L80 MF6, 10L90 MGL, 10L100 (Allison) MGM/MGU
Please observe the manufacturer's instructions and operating manual.
Characteristics
- Very good lubricating properties also at low temperatures in winter
- Protection of highly loaded gear components, thus extended service life
- Very low flow point
- Excellent oxidation stability
- Protection against wear and corrosion
- Well balanced friction properties
Բնութագրերը
Կարգավորում | Արժեք | Աուդիտ |
---|---|---|
Լայնությունը, mm | 195 | |
Երկարություն, mm | 230 | |
Բարձրություն, mm | 300 | |
Brand | RAVENOL | |
Համապատասխանում է ապրանքներին | AcDelco 10-4107, Ford 196825, Ford 2179795, GM 19352619, Motorcraft XT-12-QULV | |
Հատուկ հզորություն 20°C-ի դեպքում, գ/սմ³ | 836 | EN ISO 12185 |
Գույն | Red | տեսողական |
Մածուցիկություն 100 °C-ում, mm²/s | 4.4 | DIN 51562-1 |
Մածուցիկություն 40 °C-ում, mm²/s | 18.6 | DIN 51562-1 |
Մածուցիկության ինդեքս VI | 149 | DIN ISO 2909 |
Բրուկֆիլդի մածուցիկություն -40°C-ում, mPa*s | 2970 | ASTM D2983 |
Բյուրեղացման ջերմաստիճան, °C | -51 | DIN ISO 3016 |
Քաշը, kg | 8.831 |
Ford | 196825 |
Ford | 2179795 |
Ford | 2537407 |
Ford | 2537413 |
Ford | HU7JM2C949AA |
Ford | HU7JM2C949AB |
Ford | HU7JM2C949BA |
Ford | XT12QULV |
Ford | XT12QULV1 |
General Motors | 104107 |
General Motors | 19352619 |
General Motors | 19354795 |
General Motors | 19370721 |
General Motors | 19370828 |
General Motors | 19417737 |
General Motors | 19417911 |
General Motors | 19420403 |
General Motors | 88865897 |
General Motors | 88865954 |
